FEATURES
Support fast charging technology.
Environmentally friendly and clean energy.
Long battery life: Equipped with a built-in 314Ah high-capacity battery, providing long-term power supply, suitable for long-term outdoor activities or travel.
The portable power supply supports continuous discharge at minus 20 degrees Celsius and can be used normally in cold regions.
Safe and reliable: lt has multiple protection functions such as overcharging, over discharging short circuit,and overheating to ensure safe use.
No noise: Compared with fuel generators, portable power sources have very low noise during operation and are suitable for use in quiet environments.
Supports simultaneous charging of photovoltaic input and discharge of load, and supports AC bypass output.
Portable design: small size, light weight, easy to carry, suitable for outdoor activities travel, and mobile office.
FEATURES
MODEL | EPS-1000W |
Rate Output Power | 1000W |
PHASE | Single Phase |
Output Voltage Waveform | Pure Sine Wave |
PV INPUT(DC) |
Maximum DC Voltage | 55V |
MPP Voltage Range | 11-55V |
GRID OUTPUT(AC) |
|
Nominal Output Voltage | 230VAC |
AC INPUT |
AC Charging Power | MAX 800W |
AC Input Voltage Range | 150VAC-264VAC |
AC Input Frequency Range | 45Hz-65Hz |
BATTERY |
CellType | LiFePo4 |
Battery Capacity | 314Ah*2 |
Rate Energy | 2009.6Wh |
GENERAL |
PHYSICAL |
Dimension,D*W*H(mm) | 400*257*139.5 |
ENVIRONMENT |
Operating Temperature | 0～45℃ |
Operating Humidity | <95% |
STANDARD |
|
Protection Grade | IP21 |
DC5521 Output Characteristics |
Rated output voltage | 12+-3% |
Protection Grade | 4A max |
USB Output Characteristics |
Connection Type | USB TYPE-A |
Supporting Protocol | QC2.0/QC3.0/SCP/AFC/Apple 2.4A |
Rate Energy | 20W max |
