FEATURES
Pure sine wave solar inverter
Can work in on/off grid mode
Build in high efficiency MPPT solar controller
Wide PV input voltage range:60-500VDC
Dual MPPT solar controller for different groups solar panel
LCD display all infor mation on one interface
Build in feddback detection current sensor
Communication interface for WIFI
Fast islanding response ensures security
Easy to replace dust screen design
Product Data Sheet
MODEL | SCE3604K5SG2 | SCE3606K5SG2 | SCE36010KOSG2 |
Phase | Single-phase |
Rated Output Power | 4.5KW/4.5KVA | 6.5KW/6.5KVA | 10KW/10KVA |
PV MODE |
|
Number of MPPT | 1 | 2 | 2 |
Maximum PV Input Power | 6000W | 6000W+6000W | 6000W+6000W |
Maximum PV Input Current | 18A | 18A+18A |
PV Array Maximum Open Circuit Voltage | 500VDC |
PV Input Voltage Range | 60-500VDC |
Start Up Voltage | 120VDC |
Nominal DC Voltage | 360VDC |
MPPT Trackers Efficiency | >99.5% |
LINEMODE |
|
Phase | Single-phase |
Voltage | 230VAC |
Input Voltage Range | 90-280VAC |
Input Frequency Range | 40-65Hz |
Maximum Input Current | 30A | 30A | 45A |
Input Power Factor | >0.99 |
Input THDi | <5% |
PROTECTION |
|
Full Protection | Overload,short circuit,over-temperature,over-current,anti-islanding protection |
PHYSICAL |
|
Dimension H*W*D(mm) | 315*225*103 | 335*245*103 |
Net Weight(kgs) | 4.1 | 4.5 | 4.9 |
Gross Weight(kgs) | 4.8 | 5.2 | 5.6 |
IP Protection | IP20 |
INTERFACE |
|
Communication Port | RS-232 |
ENVIRONMENT |
|
Humidity | <95%RH(Non-condensing) |
OperatingTemperature | -10℃ to 55℃ |
