Features
Using safe and eco-friendly LiFePO4 battery,withMSDS,UN38.3,ROHS,IEC62619,UL
Support for up to 16 batteries in parallel
Focusing on the layout of the whole industrial chainofadvanced lithium battery keymaterials,batteriesbatterymanagementandsystemintegration,it hascoretechnologyintellectual property rights
Equipped with BMS Battery management systemtointelligently manage and maintain each battery unit
6000+Cycle Life,intelligent balance
The safest, environmentally friendly LithiumionPhosphate technology
Low power and no relay design.milliwatt standbyloss
Quality of vehicle specification,high quality battery
Higher energy density and efficiency
Product Data Sheet
MODEL | EB-25.6V-100AH | EB-25.6V-205AH | EB-25.6V-280AH | EB-25.6V-314AH | EB-51.2V-100AH |
Rated Voltage | 25.6V | 51.2V |
Rated Capacity | 100Ah | 205Ah | 280Ah | 314Ah | 100Ah |
Rated Energy | 2560Wh | 5250Wh | 7168Wh | 8038Wh | 5120Wh |
Voltage Range | 21.6V~29.2V | 43.2V~58.4V |
Max.Charging Current | 100A | 150A | 200A | 200A | 100A |
Recommended Charging Current | 50A | 100A | 140A | 157A | 50A |
Max.Discharging Current | 100A | 150A | 200A | 200A | 100A |
Communication Interface | RS485/CAN/WIFI/BLE |
Dimension H*W*D(mm) | 435*300*185 | 570*390*185 | 550*370*235 | 550*370*235 | 570*390*185 |
Carton Dimension, H*W*D(mm) | 490*355*255 | 625*455*255 | 610*430*255 | 610*430*255 | 625*455*255 |
Net Weight(kg) | 24.3 | 45.2 | 58.5 | 61.1 | 45.2 |
Gross Weight(kg) | 26.2 | 47.9 | 60.9 | 63.5 | 47.9 |
Humidity | 5%~95% |
Charging Temperature | 0～55℃ |
Discharging Temperature | -20～55℃ |
Storage Temperature | -20～45℃,-20～60℃(Short-term storage) |
Cycle Life | 6000 cycles at 80%DOD,25℃ |
Design Life | 10 years |
