FEATURES
Work at 2 different voltages : 12VDC or 24VDC. lt can meet different loads needs of users.
Rated power is 2300W when work at 12VDC, rated power is 4200w when work at 24VDC
Dual use on one inverter--World's first creation from SUMRY in 2025
Pure sine wave output inverter
According to the requirements ofload (household appliances/personal computers), the input voltage range of utility grid can be selected
According to the battery requirements, the charging current can be set through LCD
Solar energy and utility grid can power loads at the same time
AC inputis compatible with mains and generator
Automatic restart function when mains power is restored
Overload/Overtemperature/Short circuit protection
The intelligent charging design of battery makes the battery more fully utilized
RS485 port used for communication with BMS
Cold start functionBuilt-in MPPToperating voltage range 55V-500v, open circuit voltage 500VDC
WiFl remote monitoring Bluetooth near end sampling(optional)
Built-in anti-dust kit for harsh environment
RGB lights (optional)
PRODUCT DATA SHEET
Model | EP-4200H |
Battery Voltage | 12V | 24V |
Rated output power | 2300VA/2000W | 4200VA/4200W |
Input | 230VAC |
Voltage | 170-280VAC(For Personal Computers) |
Selectable Voltage Range | 90-280VAC(For Home Appliances) |
Frequency Range | 50 Hz/60Hz(Auto sensing) |
OUTPUT |
AC Voltage Regulation | 230VAC+5% |
Surge Power | 4600W | 8400W |
Efficiency(Peak)PV to INV | 94% |
Transfer Time | 10 ms (For Personal Computers);20 ms (For Home Appliances) |
BATTERY & AC CHARGER |
Battery Voltage | 12VDC | 24VDC |
Floating Charge Voltage | 13.5VDC | 27VDC |
Overcharge Protection | 16VDC | 31VDC |
Maximum AC Charge Current | 100A |
SOLAR CHARGER |
Maximum PV Array Power | 4000W |
MPPT Range @ Operating Voltage | 55~500VDC |
Maximum PV Array Open Circuit Voltage | 500VDC |
Maximum Charging Current | 100A |
PHYSICAL |
Dimension,D*W*H(mm) | 405*305*108 |
Net Weight(kgs) | 6.7 |
Communication interface | RS485/RS232 BMS/WIFI Bluetooth |
OPERATING ENVIRONMENT |
|
Humidity | 5% to 95% Relative Humidity (Non~condensing) |
Operating Temperature | -20℃~-50℃ |
