FEATURES
Pure sine wave inverter.
Programmable supply priority for PV,battery or Grid.
High PV input voltage range(55~ 450VDC).
Built-in Max 110A(3.8KW&6.2KW) MPPT solar charge.
Compatibe with lithium-ion battery.
Support BMS communication with Lithium battery.
Smart battery charge design to optimize battery life.
Overload,high temperature,inverter output short circuit protection.
Cold start function.
Intelligent fan speed adjustment.
Built-in anti-dusk kit for harsh enviromen.
WIFI&GPRS available for IOS and android.
PRODUCT DATA SHEET
MODEL | SP-1800W | SP-3000W | SP-3800W | SP-6200W |
Rated Output Power | 2000VA/1800W | 3200VA/3000W | 3200VA/3000W | 7000VA/6200W |
AC INPUT |
|
|
|
|
Voltage | 230VAC |
Selectable Voltage Range | 170-280VAC(For Personal Appliances) |
| 90-280VAC (For Home Appliances) |
Frequency Range | 50Hz/60Hz(Auto sensing) |
AC OUTPUT |
|
|
|
|
AC Voltage Regulation | 230VAC±5% |
Surge Power | 4400VA | 6400VA | 8000VA | 14000VA |
Efficiency(Peak)PV to INV | 98% |
Efficiency(Peak)Battery to INV | 94% |
Transfer Time | 10ms(For Personal Appliances);20ms (For Home Appliances) |
BATTERY & AC CHARGER |
|
|
|
|
Battery Voltage | 12VDC | 24VDC | 24VDC | 48VDC |
Floating Charge Voltage | 13.5VDC | 27VDC | 27VDC | 54VDC |
Overcharge Protection | 15.5VDC | 31VDC | 31VDC | 61VDC |
Maximum Charge Current | 60A | 80A |
SOLAR CHARGER |
|
|
|
|
Solar Charger Type | MPPT |
Maximum PV Array Power | 2000W | 3000W | 6000W | 6000W |
MPPT Range @ Operating Voltage | 55-450VDC |
Maximum PV Array Open Circuit Voltage solar | 450VDC |
Maximum Solar Charge Current | 80A | 110A |
|
|
PHYSICAL |
|
|
|
|
Dimension,D*W*H(mm) | 405*286*98 | 423*290*100 | 423*310*106 |
|
Carton Dimension,D*W*H(mm) |
|
|
|
|
Net Weight(kgs) | 4.5 | 5 | 7 | 8 |
Gross Weight(kgs) | 5 | 5.5 | 7.5 | 8.5 |
Communication Interface | RS232/RS485(Standard)/WIFI(Optional) |
ENVIRONMENT |
|
|
|
|
Humidity | 5% to 95% Relative Humidity(Non-condensing) |
Operationg Temperature | -10℃-50℃ |
STANDARD |
|
|
|
|
Compliance Safety | CE |
