FEATURES
Pure sine Wave solar inverter.
Big LCD Screen with richer content.
Two communication Ports for BMS and WiFi.
Dual AC output available for 3.8KW and 6.2KW.
RGB Lighting for different working mode.
Inverter running with or without battery.
Built-in Lithium Battery automatic activation .
Lithium battery intelligent charge control system : adjust the inverter charging current according to the battery information.
Internal clock function for showing PV power generation and setting AC charging time and running loads time by user.
Offline software upgrade function for adding new functions and fixing software errors.
Wide PV input voltage range 55~ 450VDC.
Built in 80A and 110A MPPT solar charger.
WIFI available for IOS and Android.
PRODUCT DATA SHEET
MODEL | RS-1800W | RS-3000W | RS-3800W | RS-3800W | RS-6200W |
Rated Output Power | 2200VA/1800W | 3200VA/3000W | 4200VA/3800W | 4200VA/3800W | 7000VA/6200W |
AC INPUT |
|
|
|
|
|
Voltage | 230VAC |
Selectable Voltage Range | 170-280VAC(For Personal Appliances) 90-280VAC (For Home Appliances) |
|
Frequency Range | 50Hz/60Hz(Auto sensing) |
AC OUTPUT |
|
AC Voltage Regulation | 230VAC±5% |
Surge Power | 4000VA | 6400VA | 8400VA | 8400VA | 8400VA |
Efficiency(Peak)PV to INV | 97% |
Efficiency(Peak)Battery to INV | 94% |
Transfer Time | 10ms(For Personal Appliances);20ms (For Home Appliances) |
TWO LOAD OUTPUT POWER |
|
|
|
|
|
Full Load | 1800W | 3000W | 3800W | 3800W | 6200W |
Maximum Main Load | - | - | 3800W | 3800W | 6200W |
Maximum EPS Load (Battery mode) | - | - | 1200W | 1200W | 1200W |
Main Load Cut Off Voltage | - | - | 22V | 44V | 44V |
Main Load Return Voltage | - | - | 27V | 54V | 54V |
BATTERY & AC CHARGER |
|
|
|
|
|
Battery Voltage | 12VDC | 24VDC | 24VDC | 48VDC | 48VDC |
Floating Charge Voltage | 13.5VDC | 27VDC | 27VDC | 54VDC | 54VDC |
Overcharge Protection | 15.5VDC | 31VDC | 31VDC | 61VDC | 61VDC |
Maximum Charge Current | 60A | 80A | 60A | 80A |
|
SOLAR CHARGER |
|
|
|
|
|
Solar Charger Type | MPPT |
Maximum PV Array Power | 2000W | 3000W | 6000W |
|
|
MPPT Range @ Operating Voltage | 55-450VDC |
Maximum PV Array Open Circuit Voltage | 450VDC |
Maximum Solar Charge Current | 60A | 80A | 60A | 80A |
|
Maximum Efficiency | 98% |
PHYSICAL |
|
|
|
|
|
Dimension,D*W*H(mm) | 405*268*98 | 423*300*120 | 423*300*120 |
|
|
Carton Dimension,D*W*H(mm) |
|
|
|
|
|
Net Weight(kgs) | 9.5 |
|
|
| 10.5 |
Gross Weight(kgs) | 10 |
|
|
| 11 |
Communication Interface | Two communication ports,one RS485 port for BMS,Another RS485/RS232/for remote monitoring |
ENVIRONMENT |
|
|
|
|
|
Humidity | 5% to 95% Relative Humidity(Non-condensing) |
Operationg Temperature | -10℃-50℃ |
STANDARD |
|
|
|
|
|
Compliance Safety | CE |
