FEATURES
Pure sine wave solar inverter(on/off Grid)
Output power factor 1.0
WIFI&GPRS available for IOS and Android
Inverter can run without battery
One-key restoration to factory Settings
Built-in Lithium battery automatic activation
Built-in 160A MPPT solar charger (for 8.2kw,10.2kw)
Dual communication ports for Battery communication and Wifi communication
High PV input voltage range(90- 500VDC)
Built-in anti-dust kit for harsh environment
Smart battery charge design to optimize battery life
Dual output
Dual PV input
Touch button
On Off Grid Work Mod
PRODUCT DATA SHEET
| MODEL | MAX-8200W | MAX-10200W |
| Phase | 1-phase |
| Maximum PV Input Power | 5400W+5400W | 5400W+5400W |
| Rated Output Power | 8200W/8200VA | 10200W/10200VA |
Maximum Solar Charging Current
| 160A | 160A |
| GRID-TIE OPERATION |
| PV INPUT(DC) |
|
Nominal DC Voltage/Maximum Current
| 360/500VDC |
Stat-up Voltage/Initial Feeding Voltage
| 90VDC/120VDC |
| MPPT Voltage Range | 90-450VDC |
| Maximum Input Current | 2/18A | 2/18A |
| GRID OUTPUT(AC) |
|
| Nominal Output Voltage | 220/230/240VAC |
| Output Voltage Range | 190-253VDC |
| Nominal Output Current | 35.6A | 44.3A |
| Power Factor | >0.99 |
| EFFICIENCY |
|
Maximum Conversion Efficiency(DC/AC)
| 98% |
| TWO LOAD OUTPUT POWER |
|
| Full Load | 8200W | 10200W |
| Maxium MainLoad | 8200W | 10200W |
Maxium Second Load(battery mode)
| 2733W | 3400W |
Maxium Load Cut Off Voltage
| 52VDC | 52VDC |
| Maxium Load Return Voltage | 54VDC | 54VDC |
| OFF-GRID OPERATION |
| AC INPUT |
|
|
AC Start-up Voltage/Auto Restart Voltage
| 120-140VAC/180VAC |
Acceptable Input Voltage Range
| 90-280VAC/170-280VAC |
| Frequency Range | 49-51HZ |
| Maxium AC Input Current | 40A | 50A |
| PV INPUT(DC) |
|
Nominal DC Voltage/Maximum DC Voltage
| 360/500VDC |
| MPPT Voltage Range | 90-450VDC |
| Maximum Input Current | 2/18A | 2/18A |
BATTERY MODE OUTPUT(AC)
|
|
| Nominal Output Voltage | 220/230/240VAC |
| Output Waveform | Pure sine Wave solar inverter |
| Efficiency(DC to AC) | 94% |
| BATTERY & CHARGER |
|
| Nominal DC Voltage | 48V |
Maximum Solar Charging Current
| 160A | 160A |
Maximum AC Charging Current
| 140A | 140A |
| Maximum Charging Current | 160A | 160A |
| HYBRID OPERATION |
| PV INPUT(DC) |
|
Nominal DC Voltage/Maximum DC Voltage
| 360/500VDC |
Stat-up Voltage/Initial Feeding Voltage
| 90VDC/120VDC |
| MPPT Voltage Range | 90-450VDC |
| Maximum Input Current | 2/18A | 2/18A |
| GRID OUTPUT(AC) |
|
| Nominal Output Voltage | 220/230/240VAC |
| Output Voltage Range | 190-253VDC |
| Nominal Output Current | 35.6A | 44.3A |
| AC INPUT |
|
AC Start-up Voltage/Auto Restart Voltage
| 120-140VAC/180VAC |
Acceptable Input Voltage Range
| 90-280VAC/170-280VAC |
| Maximum Input Current | 40A | 50A |
| Maximum AC Charging Current | 140A | 140A |
| GENERAL |
| PHYSICAL |
| Dimension,D*W*H(mm) | 500*420*160 | 500*420*160 |
Carton Dimension,D*W*H(mm)
| 618*463*205 | 618*463*205 |
| Net Weight(kg) | 15.8 | 16.2 |
| Gross Weight(kg) | 16.4 | 16.8 |
| INTERACE |
|
| Communication Port | RS232/RS485/WIFI/GPRS/REMOVE LCD |
| ENVIRONMENT |
|
| Humidity | 5% to 95% |
| Operationg Temperature | -10℃-50℃ |
| STANDARD |
|
| Compliance Safety | CE |
